Artifacts

Velociraptor allows packaging VQL queries inside mini-programs called Artifacts. An artifact is simply a structured YAML file containing a query, with a name attached to it. This allows Velociraptor users to search for the query by name or description and simply run the query on the endpoint without necessarily needing to understand or type the query into the UI.

Therefore Artifacts can be thought of as VQL modules.

Usually an artifact is geared towards collecting a single type of information from the endpoint. For example consider the following artifact:

name: Custom.Artifact.Name
description: |
   This is the human readable description of the artifact.

type: CLIENT

parameters:
   - name: FirstParameter
     default: Default Value of first parameter

precondition: ""

sources:
  - name: MySource
    precondition:
      SELECT OS From info() where OS = 'windows' OR OS = 'linux' OR OS = 'darwin'

    query: |
      SELECT * FROM info()
      LIMIT 10

The Artifact contains a number of important parameters:

  1. Name: The artifact contains a name. By convention the name is segmented by dots in a hierarchy. The Name appears in the GUI and can be searched on.
  2. Description: Artifacts contain a human readable description. The description field is also searchable in the GUI and so should contain relevant keywords that make the artifact more discoverable.
  3. Type: The type of the Artifact. Since Velociraptor uses VQL in many different contexts, the type of the artifact hints to the GUI where the artifact is meant to run. For example, a CLIENT artifact is meant to be run on the endpoint, while a SERVER artifact is meant to be run on the server. The artifact type is only relevant for the GUI.
  4. Parameters: An artifact may declare parameters, in which case they may be set by the GUI user to customize the artifact collection.
  5. Sources: The artifact may define a number of VQL sources to generate result tables. Each source generates a single table. If more than one source is given, they must all have unique names.
  6. Precondition: A source may define a precondition query. This query will be run prior to collecting the source. If it returns no rows then the collection will be skipped. Preconditions make it safe to collect artifacts from all hosts (e.g. in a hunt), and ensure that only artifacts that make sense to collect are actually run.
  7. Query: The query that will be used to collect that source. Note that since each source must produce a single table, the query should have exactly one SELECT clause and it must be at the end of the query potentially following any LET queries.

Parameters

Artifact parameters allow the user to customize the collection in a controlled way - without needing to edit the VQL. The GUI will present a form that allows the user to update the parameters prior to each collection.

Parameters may define a type. This type will be used to hint to the GUI how to render the form element. The type also determines how the parameter is sent to the client and ensures the parameter appears as that type in the query.

Prior to launching the query on the endpoint, Velociraptor will populate the scope with the parameters. This allows the VQL query to directly access the parameters.

Artifact parameters are sent to the client as strings The client automatically parses them into a VQL type depending on the parameter’s type specification. The GUI uses type specification to render an appropriate UI

Parameter types

Currently the following parameter types are supported

  • int, integer: The parameter is an integer
  • timestamp: The parameter is a timestamp
  • csv: Parameter appears as a list of dicts formatted as a CSV
  • json: Parameter is a JSON encoded dict
  • json_array: The parameter is a list of dicts encoded as a JSON blob (similar to csv)
  • bool: The parameter is a boolean (TRUE/YES/Y/OK)

Example

Let’s take a look at a typical artifact Windows.Detection.Mutants.

Mutants artifact
Mutants artifact

This artifact uncovers the mutants (named mutexes) on a system, using two methods. First we enumerate all handles, and check which process is holding a handle to a mutant object. Alternatively we enumerate the kernel object manager to receive the same information.

Therefore this artifact contains two sources - each gets similar information in a different way. A user who is just interested in listing the Mutants on an endpoint would probably need to see both results.

We also see some parameters declared to allow a user to filter by process name or mutant name.

Preconditions and source queries

A precondition is a query that is run before collecting the artifact to determine if the artifact should be collected at all. The precondition makes it safe to collect artifacts without needing to worry about if the artifact is designed for this particular architecture or operating system. For example, performing a hunt for a Windows only artifact is safe to target all clients because Linux clients will just ignore it and return no rows. Most preconditions target specific operating systems or architectures but the precondition can be an arbitrary query.

You can specify a precondition at the top level of the artifact or at each source:

  • For a top level precondition, after testing for the precondition, the queries from each source are run in series within the same query scope. This means you can define a VQL variable in an earlier source and use it in another source.
  • If the precondition is specified at the source level, the VQL engine has no idea if any particular source will be use or not. Therefore the engine treats each source as an independent query within its own scope. Since sources are independent they will run in parallel and any VQL variable defined in one source will not be visible to other sources.

Artifact writing tips

Typically we have a new idea for a new detection. The first step is to develop the VQL that will detect the anomaly by writing the VQL in a notebook cell on the target operating system itself (usually we use velociraptor gui to start a new local server).

While developing the VQL, Use the log() VQL function librally to provide print debugging.

Use format(format="%T %v", args=[X, X]) to learn about a value’s type and value.

Calling artifacts from VQL

You can call other artifacts from your own VQL using the Artifact.<artifact name> plugin notation. Args to the Artifact() plugin are passed as artifact parameters.

Calling artifacts
Calling artifacts

When calling artifacts types are not converted. Make sure you pass the expected types

When collecting an artifact from the client, the server compiles the artifact and it’s dependencies into raw VQL statements and sends these to the client for evaluation. We never rely on the artifact definitions embedded in the client itself - instead we always send the compiled VQL to the client. This allows us to upgrade artifact definitions on the server without needing to update the client itself.
